SALIENT FEATURES

• Microprocessor Based with Printer Interface
• Four element measurement in single aspiration of the sample
• Calibration curve programmability using maximum of 5 standards.
• Data processing through curve fitting techniques – least squares, quadratic
• Multiple calibration curve saving facility
• Samples data storage facility
• Printer attachment facility
• Measures in ppm & meq
• Useful for both medical & soil testing application


TECHNICAL SPECIFICATIONS

MODE       RANGE       General Range                Serum range             Urine Range
(ppm)              (meq)             (meq)                    (meq)
Na: 0-100             Up to 250meq/I,        0-200meq/I          0-250meq/I,
I: 100dil.
K: 0- 100           Up to 250meq/I,        0-10meq/I                 0-100meq/I
Li: 0- 100             Up to 250meq/I,        0-2meq/I               - - - - - -
I: 5dil.  Ca:0- 100             Up to 250meq/I,        - - - -                0-10meq/I

SENSITIVITY
General Mode:
Na:0. 5ppm, K:0. 5ppm, Li:0.5ppm, Ca: 15ppm


• FILTERS  Na & K Supplied (Ca & Li are optional at extra cost)
• RESOLUTION                            0.1 ppm/meq.
• REPRODUCIBILITY                  + 2%fs + 2 Digits
• CURVE FIT ACCURACY         + 2% of FS
• DISPLAY          20x4 Character alphanumeric LCD display with backlit
• AVERAGE TIME                        in –built in Software
• FLAME SYSTEM                       LPG & Dry Oil Free Air
• DETECTOR                                Photodiode
• CALIBRATION        Up to 5 Point Calibration with Curve Fitting Software
•  GAS CONTROL                         Adjustable with Knob
•  IGNITION SYSTEM                   Auto Ignition
• COMBUSTION GAS                  LPG?
• AUTOMISER                              Axial Flow Type
• DIMENSIONS                             365x245x220mm Approx. (LxBxH)
• PRINTER            Provision for attachment of Dot – Matrix Printer or HP
• Laserjet/ Inkjet printer (non-win printers) with Centronics
• Parallel interface.         RS 232 INTERFACE
• Available (PC software at extra cost)

• AIR COMPRESSOR   :With Built –in Regulator And Air Filter to deliver stable And moisture/ oil free air supply
• AIR SUPPLY :    By Oil Free Mini Compressor Unit With Pressure Regulator
• WEIGHT               Main Unit: 8Kg. (Approx.) Compressor: 8Kg. (Approx.)
• POWER SUPPLY                      230V AC + 10%, 50Hz.


COMPRESSOR UNIT

• AIR SUPPLY        By oil free mini compressor unit with pressure regulator
• COMBUSTION GAS LPG        Controlled by precision regulator?
• POWER                                       230V + 10% AC, 50Hz.
• DIMENSIONS                             275W X 192H X 240 D mm (Approx.)
• WEIGHT                                      6.25Kg. (Approx.)
