TECHNICAL SPECIFICATIONS

MAIN UNIT

• RANGE
• Na: 0 –100 ppm
• K:   0- 100 ppm
• Ca: 15 –100 ppm (Optional)
• Li: 10-100 ppm (Optional)

SENSITIVTY

• Sodium (Na)           : 5 ppm
• Potassium (K)      : 5 ppm
• Calcium (Ca)       : 10 ppm (Optional)
• Lithium (Li)      : 10 ppm (Optional)

• READOUT                                  2½ digit bright red LED display
• ACCURACY                               + 2% up to 40 ppm, + 5% above 40 ppm
• IGNITION SYSTEM                   Auto Ignition
• DIMENSIONS                             375 X 275 X 220 mm (Approx.)
• WEIGHT                                      7.5 Kg. (Approx.)
• MEASUREMENT                       Measures one element at a time
• REPEATABILITY                       + 2 Counts
• DETECTOR                                Silicon Photodiode
• FITLER                                        Narrow band interference glass filters
• NEBULIZER                               Black bakelite, axial flow type
• FLAME SYSTEM                       LPG & dry oil free air
• WARM UP TIME                        10 minutes
• POWER                                       230V + 10% AC, 50Hz.


COMPRESSOR UNIT (For all Flamephotometer)

• AIR SUPPLY          By oil free mini compressor unit with pressure regulator
• COMBUSTION GAS LPG         Controlled by precision regulator
• POWER                                       230V + 10% AC, 50Hz.
• DIMENSIONS                             275W X 192H X 240 D mm (Approx.)
• WEIGHT                                      8Kg. (Approx.)
