TECHNICAL SPECIFICATION

• GENERAL PARAMETERS    pH, mV and Temperature
• DISPLAY    7- segment bright Red LED Display (3 for Temperature and 4 pH/mV)
• KEY BOARD    6 Keys, soft touch membrane type
• POWER SUPPLY    230 + 10% VAC, 50Hz.

• pH RANGE                0.00 to 14.00 pH
• RESOLUTION            0.01 pH
• RELATIVE STABILITY        0.02 pH/Hour
• ACCURACY            + 0.01 Ph + I Digit
• TEMPERATURE COMPENSATION    0 – 100ºC
• CALIBRATION                         Auto (2 or 3-point)
• AUTO BUFFER RECOGNITION 4.00, 7.00 & 9.20pH
• ACCEPTABLE ELECTRODE SLOPE70% TO 130%
• mV RANGE    0 to + 1999 mV
• RESOLUTION    I mV
• RELATIVE ACCURACY    + I mV + I digit
• TEMPERATURE  RANGE                0 – 100ºC
• RESOLUTION            0.1 ºC
• ACCURACY            + 0.1 ºC
• SENSOR                Semi – conductor (LM35) Type
• DIMENSIONS            275 X 182 X 85mm
• WEIGHT                3.5 Kg. (Approx.)


Standard Accessories – 1010

•     Combined pH Electrode    1 No.
•     Temperature Probe        1 No.
•     Dust Cover            1 No.
•     Instruction Manual        1 No.
•     Electrode Stand            1 No.
•     Buffer Tablets 4& 7pH        2 Nos. each
•     Main Lead            1 No.
