SALIENT FEATURES

•     Highly Accurate & Stable
•     % Transmission and Absorbance Modes
•     Auto Zeroing Facility
•     Range 400 to 700nm
•     Soft Touch Membrane Keys

TECHNICAL SPECIFICATION

•     WAVE LENGTH RANGE    400TO 700nm
•     RESOLUTION            1% T, 0.01 Abs
•     % TRANSMITTANCE        0 – 100%
•     ABSORBANCE            0 – 1.99
•     PHOTO DETECTOR        Silicon Photodiode/ Photo Cell
•     DISPLAY                3 Digit 7 Segment Bright Red LED Display
•     KEYBOARD            2 Keys, Soft touch membrane type
•     AUTO ZEROING        Available 0.00 for Abs. And 100% for %T
•     LIGHT SOURCE        6.3V, 0.3Amp. Tungsten lamp
•     SOLUTION VOLUME        1ml (Minimum)
•     SAMPLE SYSTEM        10mm path length matched glass test tubes
•     OPTICAL FILTERS        8 filters mounted on the turrent
•            400, 420, 480, 500, 520, 540, 520, 620, 680nm
•     WEIGHT                2.5 Kg. Approx
•     Power supply            230V + 10%AC 50Hz. With in –built Stabilizer
•     ACCESSORIES           A Set of 5 Matched Test Tubes, *Operation Manual, DustCover, Spare lamp
•     DIMENSIONS            190 X 165 X 225mm
